High-Speed Digital-Input Current Limiters From STMicroelectronics Cut Power, Cost, And Board Space In Factory Automation

STMicroelectronics has introduced two high-speed N3817I -- Apr 18 2016 -- High-speed current limiters_IMAGEdigital-input current limiters that set new standards for circuit protectionin factory automation. The SCLT3-8BQ7 and CLT01-38SQ7 provide industrial Programmable Logic Controllers(PLCs) – the “brains” of smart factories and industrial robots –with fast, robust protection against unwanted input-signal current spikes while reducing power consumption, board space, and component costs.

The new devices meld ST’s long-standing leadership in Transient Voltage Suppressors[1] with its state-of-the-art packaging technology.Both devices are housed in the highly compact QFN-48L (7x7mm)package with a large exposed thermal pad that optimizes power dissipation at ambient temperatures greater than 100ºC.
Key technical features include:

  • 8 high-speed SPI protected outputs;

  • 8/16-bit high-speed SPI output;

  • High-side inputs with common ground;

  • Integrated 5V regulator;

  • 30V+ reverse polarity protection;

  • Energy-free LED output signal for visual status indication;

  • 78mW/channel power-dissipation capability;

  • Temperature/voltage alarm options.

The high-speed inputs and outputs are fully compliant with the requirements of best-in-classPLCs.

The CLT01-38SQ7 also delivers robustness compliant with the most stringent international EMC (Electromagnetic Compatibility) standards such as IEC 61000-4.2, IEC61000-4.4, and IEC6100-4.5.
The SCLT3-8BQ7 and CLT01-38SQ7 are now available in volume at $0.9 for 1,000-unit quantities.Also, evaluation boards are available for both the SCLT3-8BQ7 (STEVAL-IFP030V1) and the CLT01-38SQ7 (X-NUCLEO-PLC01A1).
